Accu Trak "CP" Series Metric Cut Type Knurls Circular Pitch Hi-Cobalt Steel
- $21.31$30.45
30% OFF"Cut Type" knurls are designed for use in "Cut Type" holders, but may be used in "Form Type" holders also.Accu Trak's "Cut Type" knurls are made from "Hi-Cobalt" steel and have a "smooth tooth profile".*These wheels have a Lapped/Polished Tooth Profile.Made in USA CPLX0.6 - In-stockCPLX1.0 - In-stockPlease indicate the product "Type" in the comment box upon checking out. **For other sizes, please refer to "Specifications" and send us an enquiry for prices**
Out Of Stock!
This product is out of stock, submit your email and we will update once it restock.
CP SERIES
(15 X 4 X 8mm)
.591 x .157 x .315"
"CUT TYPE KNURLS"
-
8% Hi-Cobalt Steel
-
Smooth Tooth Profile
-
Multiple Coatings Available
Circular Pitch - CP - SERIES - Hi-Cobalt Steel | ||||||
| Included Tooth Angle | Pitch Inch/Metric | AA Straight
| BL 15° LH Diagonal
| BR 15° RH Diagonal
| BL 30° LH Diagonal
| BR 30° RH Diagonal
|
| 90º | 0.4mm / 63.5 TPI | CPSX0.4 | - | - | CPLX0.4 | CPRX0.4 |
| 90º | 0.5mm / 50.8 TPI | CPSX0.5 | CPAX0.5 | CPBX0.5 | CPLX0.5 | CPRX0.5 |
| 90º | 0.6mm / 42.3 TPI | CPSX0.6 | CPAX0.6 | CPBX0.6 | CPLX0.6 | CPRX0.6 |
| 90º | 0.7mm / 36.3 TPI | CPSX0.7 | CPAX0.7 | CPBX0.7 | CPLX0.7 | CPRX0.7 |
| 90º | 0.8mm / 31.8 TPI | CPSX0.8 | CPAX0.8 | CPBX0.8 | CPLX0.8 | CPRX0.8 |
| 90º | 0.9mm / 28.2 TPI | CPSX0.9 | - | - | - | - |
| 90º | 1.0mm / 25.4 TPI | CPSX1.0 | CPAX1.0 | CPBX1.0 | CPLX1.0 | CPRX1.0 |
| 90º | 1.2mm / 21.2 TPI | CPSX1.2 | CPAX1.2 | CPBX1.2 | CPLX1.2 | CPRX1.2 |
| 90º | 1.5mm / 16.9 TPI | CPSX1.5 | CPAX1.5 | CPBX1.5 | CPLX1.5 | CPRX1.5 |
| 90º | 1.6mm / 15.9 TPI | CPSX1.6 | - | - | - | - |
| 90º | 1.8mm / 14.1 TPI | CPSX1.8 | CPAX1.8 | CPBX1.8 | - | - |
| 90º | 2.0mm / 12.7 TPI | CPSX2.0 | - | - | - | - |
| Series | CP [15x4x8] |
| Steel Type | Hi-Cobalt Steel |
| Included Tooth Angle Degrees | 90 |
| Treatment | N/A |
| Standard of Measure | Metric |
| Pitch Type | Circular |
| Size Diameter mm | 15mm |
| Size Width mm | 4mm |
| Size Hole mm | 8mm |
